eneo IND-58F0002MTPB

SKU 246665
Network Dome Camera Fix, Turret, Panorama 180°, 2x 5120x1440, Day/Night, DWDR, AI, 2x 2,8mm, IR, White Light, 12VDC, PoE, IP67
Data sheet

Specifications

Manufacturer order number 246665
EAN/GTIN 4260229841884
Series eneo IN-Serie
Alarm processing Recording internal storage (SD card),E-Mail,HTTP,FTP,TCP,UDP,Red & bule flashing lights,Cloud Upload
Analysis Crowds (CD), Enter Region, Face, Heat Map (HM), Intrusion, Leave Region, License plate recognition (LPR), Line crossing (LCD), Object classification, Object Classification Human / Vehicle (PD&VD), People counting, Queues (QD), Rare Sounds (RSD)
Aperture Range (F) F1,2
Audio 2 Way Audio, Built-in microphone, Built-in speaker
Audio compression G.711a, G.711u
Audio support Yes
Backlight compensation Yes
Brand eneo
Browser Edge, Firefox, Google Chrome, MS Internet Explorer 10/11, Safari
Camera Type Panoramic camera
Camera shape Minsters
Chip size 1/2,7"
Color (Housing) RAL9003,Other colors available upon request
Control Interfaces Ethernet
Data stream types Dual Streaming
Day/night mode Day,Night,Automatic,Time
Day/night switching Switchable IR Filter (ICR)
Detect (125px/m) 11,7m
Digital Noise Reduction (DNR) Yes
Dimensions (WxHxD) (extended) 112,4x135 mm
ESC 1/5 ~ 1/20.000sec.
Ethernet interface 100Base-TX, 10Base-T
External connections RJ-45,12VDC input (DC plug),connection cable approx.30cm,micro SD card slot 256 GB
Flickerless function Yes
Focal length 2,8 mm
Horizontal angle of view 180°
Housing material Aluminium
Housing type Outside
Identify (250px/m) 5,5m
Illumination range Approx. 30 m | Approx. 15 m Warm light
Image resolution max. 5120x1440
Image transfer rate max. 15 fps
Internal memory microSD card slot
Lens Type Prime lens
Lighting Infrared, Warm Light
Low Speed Shutter Yes
MOD (Minimum Object Distance) 2 m
Manual Electric Shutter (MES) 1-5~1-20,000sec.
Menu languages English, French, German, Italian, Japanese, Portuguese, Spanish, Turkish
Motion detector Yes
Mounting type Ceiling, Wall
Multicast Yes
Network Protocols DDNS, DHCP, DNA, FTP, HTTP, HTTPS, IPv4, IPv6, NTP, PPPoE, RTP, RTSP, SMTP, TCP-IP, UPnP, UTP
ONVIF ONVIF Profile G, ONVIF Profile M, ONVIF Profile S, ONVIF Profile T
Password Administrator and User
Perceiving (25px/m) 60,1m
Photosensitivity 0.001 Lux bei (F1.6,AGC ON)
Power consumption 13.5 W
Power over Ethernet IEEE 802.3af
Power supply 12VDC, Poe
Privacy Zone Areas-ON/OFF switchable
Protection IP67, NEMA 4X
Recording sensor Chipset NT98529, CMOS, SC533HAI
Remark Face and license plate recognition require an SD card or an eneo IN recorder. For optimal results,use only eneo components. For mixed brands,we offer a compatibility check for a fee (info: item #229235 at VIDEOR).
Resolution (extended) 5120x1440,4608x1296,4096x1152,3840x1080,3072x864,1536x432,1024x288
Resolution standard 8 MP
SDK Upon request
Scope of delivery Quick installation guide,drilling template,3x wall plugs with screws,1x Allen wrench,1x waterproof cover for RJ45 connector
Security Complicated password, HTTPS encryption, IP address filtering, Password
Signal-to-noise ratio 49 dB
System True Day&Night
Temperature Range (Operating) -30°C ~ +60°C,@ Luftfeuchtigkeit 90% oder weniger (nicht kondensierend)
Text overlay Switchable on/off
Vertical angle of view 60°
Video Compression H.264, H.264+, H.265, H.265+, MJPEG
Watch (62px/m) 23,8m
Weight 0.765 kg
White balance Automatic,Manual
Wide Dynamic Range (WDR) WDR 120dB

Main Features

  • Multisensor 2x 1/2.7’ CMOS sensor, panorama
  • Maximum resolution 5120x1440 pixels each, 15fps
  • Panorama ultra wide-angle camera 180° HFoV, 32:9
  • AI analysis functions including object classification
  • WDR, BLC, HLC and 3D-DNR noise reduction
  • Lenses with 2.8mm fixed focal length
  • Smart Codec H.265/H.264, dual streaming
  • Browser-independent (Edge, Safari, Firefox, Chrome)
  • Supports ONVIF profiles S/T/G/M and audio
  • Local storage via micro SD card
  • NDAA compliance
  • Integrated IR and white light LED illumination, IP67
