Solvido IQbox-mini-C
SKU 246007
camera connection box for video security application, 300x200x150mm
For Prices and Availability please login.
calcActive())">
Specifications
| Manufacturer order number | 246007 |
|---|---|
| Series | IQbox-mini-C |
| Brand | Solvido |
|---|---|
| Certifications | IK10 |
| Color (Housing) | RAL7035 |
| Housing material | Polycarbonate |
| Installation Location | Outdoor |
| Mounting type | Mast mounting, Wall |
| Power supply | 230VAC |
| Protection | IP66 |
| Temperature Range (Operating) | -40°C ~ +80°C |
Main Features
- Optimised for outdoor use
- UV-stabilised polycarbonate, corrosion-resistant
- Colour: RAL7035
- Protection rating (EN 60529): IP66
- Impact resistance (EN 62262): IK10
- Halogen-free (DIN/VDE 0472, Part 815): Yes
- Door with PUR seal, hinge on long side
- 1-point locking with double-bit latch
- Steel mounting plate
- Pre-wired, for flexible, modular expansion
- Includes 1-pole 6A circuit breaker
- Wall or pole mounting
Downloads
-
Data sheet with specifications generated live from the product database
-
Technical data as Word document, generated live from the product database
-
Manufacturer data sheet (german)
-
Manufacturer data sheet (english)
