SFP-1310S40

SFP Modul, 1.25Gbps, 20km, Singlemode, 1310nm, Duplex LC Connector -40°~+75°C
SKU
216477
Main Features
  • Compatible to IEEE802.3z Gigabit Ethernet Standard
  • Bandwith 1,25Gbps
  • Compliant with Fibre Channel 100-SM-LC-L
  • Industry standard small form pluggable (SFP) package
  • Duplex LC connector, 1310nm
  • Differential LVPECL inputs and outputs
  • Single power supply 3.3V
  • Hot Pluggable
  • Class 1 laser product complies with EN 60825-1
  • Distance 9/125 µm SMF 20km
  • Temperature range -40° ~ +70°C
More Information
Brand eneo
Type SFP-Modul
Fiber optic connector Duplex LC
Transmission medium optical fiber
Operation mode 3 single mode
Number of fibers 2
Wavelength 1310nm
Range 20 km
Operating temperature -40°C ~ +75°C
Weight 17g
Manufacturer order number 216477
