IAD-5SG1004MUC

SKU 237369
Gigabit Switch, Unmanaged, 60W, 4x PoE, 1x RJ45, 1x SFP, 10/100/1000 Mbps, Desktop
Data sheet

Camera not included

Specifications

Manufacturer order number
237369
Brand
eneo

Functions

Security
CCTV mode

Network

Eneo _netzwerkstandards
IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, IEEE 802.3x Flow Control
Internal Switching Capacity (MP per second)
8.9 Mpps
Internal Switching Capacity (Gbit)
12 Gbps

Interfaces / Inputs/ Outputs

Ethernet interface
1000Base-T, 100Base-TX, 10Base-T
Ports
1x 10/100/1000Base-T, 1x 1000Base-X SFP, 4x 10/100/1000Base-T (PoE)

General

Design
Desktop
Dimensions (WxHxD) (extended)
27x135x86mm
Weight
300 kg
Number of PoE ports
4
Type
Unmanaged
Power consumption
65 W
Mounting type
Desktop
PoE Budget (Total)
60 W
Power over Ethernet
IEEE 802.3af, IEEE 802.3at
Power supply
48-57 VDC
Temperature Range (Operating)
-5°C ~ +45°C
Application environment
inside
ESD protection
IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6

Parts supplied

Scope of delivery
manual,power cord,Mounting Bracket,PSU

Main Features

  • Gigabit PoE switch, desktop application
  • 4x 10/100/1000 PoE+ ports, IEEE 802.3af/at
  • Gigabit uplink ports: 1x RJ45, 1x SFP
  • Up to 30W per port, total ≤60W.
  • Overvoltage protection IEC61000-4-5 (6KV).
  • Temperature range (operation) -5°C~45°C
  • CCTV mode enables transmission up to 250m @10Mbps
  • CCTV mode supports PoE watchdog function
  • Plug and Play, no settings required
  • Metal housing
