WDR-480-48 Industrial Power Supply
SKU 245313
Input 230VAC, Output 48VDC, for DIN RAIL TS-35/7.5 or 15 Operating temperature from -30 °C to +70 °C
For Prices and Availability please login.
new
Specifications
| Manufacturer order number | 245313 |
|---|
| Brand | Jetrics |
|---|
Main Features
- DIN rail power supply for industrial applications with 480 W
- Input voltage range: 180-550 V AC, 3-phase
- Output: 48 V DC / 10 A
- Analogue interfaces: Relay output for DC OK
- Efficiency up to 91%
- Fanless design, cooling by free convection
- Operating temperature from -30 °C to +70 °C
- Protection against overload, overvoltage, overtemperature, short circuit
- EMC standards: EN 55032
- Safety standards: UL 61010-1, UL 61010-2-201, EN 61558-1,
- EN 61558-2-16, CE, UKCA mark
Downloads
-
Data sheet with specifications generated live from the product database
-
Technical data as Word document, generated live from the product database
-
Manufacturer data sheet (german)
